Model NO.
Fully Welded Ball Valve
Quantity:

Since the seat of the API 6D fully welded ball valve is made up of a carbon teflon seal ring and a disc spring, it is adaptable to changes in pressure and temperature and will not produce any leakage in the marked pressure and temperature range.

Fully welded ball valves are widely used in domestic steel mills, petroleum, chemical, gas, boiler, paper, textile, pharmaceutical, food, ship, water supply and drainage, energy, polysilicon, electricity and so on.


Structure: Fully Welded Body

Size: 2”~60” (50mm~1500mm)

Class: 150LB~2500LB

Working Temperature:-29℃~+150℃

Connection Ends: Flange, Butt Weld

Operator: Lever, Gear, Electric, Pneumatic etc.


Standards:

Design: API 6D, ASME B16.34, API 608

Pressure and Temp. Range: ASME B16.34

Inspection and Test: API598

Flange Ends: ASME B16.5

Butt Weld Ends: ASME B16.25,

Fire Safe: API 607

NACE MR-0175


Main Materials:

Body Materials: A105 (N), LF2, F304, F316, F51, F55 etc.

Ball Materials: A105+ENP, F304, F304L, F316, F316L, F51, Inconel, etc.

Stem Material: 17-4PH, XM-19, F304, F316, F51 etc.

Seat Material: PTFE, PPL, RPTFE, DEVLON, NYLON, PEEK, SS+Ni/ STL.


Design Feature:

Full Bore or Reduce Bore

Double Exhaust Structure

Double Block & Bleed Design

CAPI/ISO 5211 Mounting Pad

Blow-out Proof Stem

Integral Body Structure

Anti-fire Safe Design

Anti-static Device

Zero Leakage
